等离子喷涂胶带2975-8R
等离子喷涂胶带2975-8R
- 产品详情
- 产品参数
产品特性：由硅橡胶涂覆玻璃纤维布，高温特质硅胶，耐高温性可达到900度，不燃烧。
用途：
用于喷砂和等离子超音速喷涂遮蔽保护，丝材、HVAF、HVOF等行业。
CHR® Cloth-Glass Silicone Tape
CHR® 23816 is manufactured from silicone rubber/fiberglass cloth backing coated with high-temperature silicone adhesive. 23816 tape is used in the plasma spray process.
CHR® 2965-8R and 2975-8R are manufactured from silicone rubber/fiberglass cloth backing coated with high-temperature backing. 2965 and 2975 are used in the plasma spray process.
CHR® H7525 and H7575 (HVOF) are heavy-duty pressure-sensitive tapes used for thermal spray masking. They are manufactured by combining multiple layers of silicone rubber, aluminum foil and fiberglass coated with aggressive high-temperature silicone adhesive. H7525 and H7575 are used as high-temperature masking tapes in thermal spray and high velocity oxygenated fuel processes.
The aerospace industry is the prime market for the use of plasma spray tapes, specifically jet engine manufacturers, overhaul centers, major airline maintenance centers, Air Force Bases, and Naval Air Rework Facilities.
CHR® Brand Cloth Glass-Silicone Tape
| Part # | Color | Adhes. System | Backing Thickness | Adhesive Thickness | Total Thickness | Adhesion Strength | Tensile Strength | Elong. | Temperature Range | ||||||||
| mil | mm | mil | mm | mil | mm | oz/in | g/cm | lbs/in | kg/cm | % | Min °F | Max °F | Min °C | Max °C | |||
| GLASS-SILICONE | |||||||||||||||||
| 23816 | White | S | 8.0 | 0.203 | 4.0 | 0.102 | 12.0 | 0.305 | 50 | 551 | 100 | 18.0 | -- | -100 | 500 | -73 | 260 |
| Blue | S | 7.0 | 0.178 | 3.5 | 0.089 | 10.5 | 0.267 | 45 | 496 | 100 | 18.0 | 15 | -100 | 500 | -73 | 260 | |
| 2975-8R | White | S | 7.0 | 0.178 | 3.5 | 0.089 | 10.5 | 0.267 | 50 | 551 | 150 | 27.0 | 5 | -100 | 500 | -73 | 260 |
| H7575 | White | S | 17.5 | 0.440 | 3.5 | 0.089 | 21.0 | 0.553 | 50 | 551 | 180 | 32.7 | -- | -100 | 500 | -73 | 260 |
| H7525 | White | S | 15.0 | 0.380 | 2.5 | 0.064 | 17.5 | 0.445 | 50 | 551 | 125 | 22.0 | -- | -100 | 500 | -73 | 260 |
| HV60 | Blue | S | 18.0 | 0.460 | 3.0 | 0.076 | 21.0 | 0.553 | 25 | 275 | 150 | 27.0 | -- | -100 | 500 | -73 | 260 |
| NOTE: For 23816, 2965-8R, 2975 and H7575, a yellow-dimpled PVC liner is standard. For H7525, a Kraft paper liner is standard. | |||||||||||||||||
